The RT4801A is a highly integrated Boost and LDO and inverting charge pump to generate positive and negative output voltage. The output voltages can be adjusted from ±4V to ±6V with 100mV steps by I2C interface protocols. With its input voltage range of 2.5V to 5.5V, RT4801A is optimized for products powered by single-cell batteries and symmetrical output currents up to 80mA. The RT4801A is available in the WL-CSP-15B 1.31x2.07 (BSC) package.
Applications
- TFT-LCD Smartphones
- TFT-LCD Tablets
- General Dual Power Supply Applications
